The API (yes, an API for your APIs)

MXroute Manager already talks to MXroute and Cloudflare on your behalf. The HTTP API is the same machinery, exposed so you can script it: provision a mailbox from CI, fix DNS from a cron job, or glue this app into whatever automation stack you already run.

You are not getting a second mail platform. You are getting a polite middle layer that speaks JSON while the upstream services keep doing their thing.

Two ways to authenticate

Client	How	CSRF on writes
Browser	Session cookie after login	Yes (X-CSRF-Token header)
Automation	Authorization: Bearer mxm_… API token	No

Browser sessions

Sign in through the UI (or OIDC). Mutating requests (POST, PUT, PATCH, DELETE) must include the CSRF token from the session or the csrf_token cookie:

X-CSRF-Token: <token from cookie or page>
Content-Type: application/json

API tokens (recommended for scripts)

Create tokens under Access Control → API Tokens (admin browser session only). Each token is shown once at creation. Store it like a password.

Format:

mxm_<random-url-safe-string>

Example request:

curl -sS \
  -H "Authorization: Bearer mxm_your_token_here" \
  -H "Content-Type: application/json" \
  https://manager.example.com/api/domains/example.com/email-accounts

Tokens use the same permission model as delegated users. A token with emails on example.com can manage mailboxes there but cannot touch other domains. Admin tokens have full API access except they cannot create or revoke other API tokens (that stays in the UI on purpose).

Base URL and health

Endpoint	Auth	Purpose
GET /health	Public	{"status":"ok"} for load balancers and Docker healthchecks
GET /api/me	Session or token	Current user, grants, admin flag
GET /api/docs	Admin session	Human-readable route catalog in the browser
GET /api/openapi.json	Admin session	Machine-readable route list (OpenAPI 3 skeleton)

Replace https://manager.example.com with your real manager hostname in every example.

Response shape

Successful JSON responses usually look like:

{
  "success": true,
  "data": { }
}

Errors:

{
  "success": false,
  "error": {
    "message": "Human-readable reason"
  }
}

HTTP status codes follow the usual pattern: 401 unauthorized, 403 forbidden (wrong domain or permission), 400 validation, 404 not found.

Permissions (scopes)

API tokens and delegated users share these permission keys:

Permission	Typical routes
dashboard	Domain stats, quota views for a domain
emails	Mailboxes, recovery email, mail client settings
forwarders	Forwarders, catch-all, pointers
spam	SpamAssassin settings and lists
dns	DNS health, Cloudflare fixes, setup wizard pieces

Admins bypass checks. Everyone else is limited to domains listed on their token or delegation.

Full matrix: Access control.

Common automation recipes

List domains

curl -sS -H "Authorization: Bearer $MXM_TOKEN" \
  https://manager.example.com/api/domains

List mailboxes on a domain

curl -sS -H "Authorization: Bearer $MXM_TOKEN" \
  https://manager.example.com/api/domains/example.com/email-accounts

Create a mailbox

curl -sS -X POST \
  -H "Authorization: Bearer $MXM_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"username":"alex","password":"Abcd123!","quota":1024,"limit":9600}' \
  https://manager.example.com/api/domains/example.com/email-accounts

Preview a CSV mailbox import

Validate rows before creating mailboxes (same permission checks as create). The UI parses CSV client-side, then calls this endpoint:

curl -sS -X POST \
  -H "Authorization: Bearer $MXM_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"default_domain":"example.com","rows":[{"username":"alice","password":"Abcd123!"}]}' \
  https://manager.example.com/api/email-accounts/import/preview

Creation still uses one POST per mailbox (the UI caps parallel requests at 3). Download the template from Email Accounts → Import CSV in the app. Export uses the same columns (passwords left blank). See Bulk mailbox CSV.

Fetch IMAP/SMTP settings for a mailbox

curl -sS -H "Authorization: Bearer $MXM_TOKEN" \
  "https://manager.example.com/api/domains/example.com/mail-client-settings?username=alex"

Fix missing mail DNS (single domain)

curl -sS -X POST \
  -H "Authorization: Bearer $MXM_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{}' \
  https://manager.example.com/api/domains/example.com/dns/fix

Deploy only webmail CNAME:

curl -sS -X POST \
  -H "Authorization: Bearer $MXM_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"records":["webmail"]}' \
  https://manager.example.com/api/domains/example.com/dns/fix

Bulk fix unhealthy DNS (admin)

curl -sS -X POST \
  -H "Authorization: Bearer $MXM_ADMIN_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"only_unhealthy":true}' \
  https://manager.example.com/api/cloudflare/dns/fix-bulk

Webmail is opt-in per domain; bulk fix does not add webmail CNAMEs automatically.

Example scripts (PowerShell and Bash)

Ready-made scripts live in docs/examples/:

Script	Use case
deploy-mailbox.ps1 / deploy-mailbox.sh	Provision a mailbox from a terminal or CI job
blacklist-sender.ps1 / blacklist-sender.sh	Add an address to SpamAssassin blacklist (Karen from HR, politely)

Set MXM_URL and MXM_TOKEN, create a scoped API token, then run. The PowerShell mailbox example:

$env:MXM_URL = "https://manager.example.com"
$env:MXM_TOKEN = "mxm_your_token_here"
.\docs\examples\deploy-mailbox.ps1 -Domain "example.com" -Username "alex" -Password "Abcd1234!"

Blacklist example (requires spam on the domain):

.\docs\examples\blacklist-sender.ps1 -Domain "example.com" -Entry "karen@hr.example.com"

Bash equivalents use curl and the same env vars. See each script's header comments.

SpamAssassin API quick reference

# List blacklist
curl -sS -H "Authorization: Bearer $MXM_TOKEN" \
  https://manager.example.com/api/domains/example.com/spam/blacklist

# Add entry (local part or full address)
curl -sS -X POST \
  -H "Authorization: Bearer $MXM_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"entry":"karen@hr.example.com"}' \
  https://manager.example.com/api/domains/example.com/spam/blacklist

# Remove entry (URL-encode special characters)
curl -sS -X DELETE \
  -H "Authorization: Bearer $MXM_TOKEN" \
  "https://manager.example.com/api/domains/example.com/spam/blacklist/karen%40hr.example.com"

Route groups (cheat sheet)

The in-app Settings → API reference link opens /api/docs with the live route table. Broad groups:

Tag	Examples
Domains	/api/domains, /api/domains/<domain>, mail hosting toggle
Mail	/api/domains/<domain>/email-accounts, forwarders, catch-all
DNS	/api/domains/<domain>/dns/setup-health, /dns/health, /dns/fix, /dmarc-policy, reset portal
Cloudflare	/api/cloudflare/status, /api/cloudflare/dns/fix-bulk
Spam	/api/domains/<domain>/spam/*
Admin	/api/admin/settings, delegations, logs, notifications
Public	/api/public/password-reset/* (mailbox self-service, no manager login)

Path parameters use the real domain name (example.com), not an internal ID.

DMARC policy per domain

curl -sS -H "Authorization: Bearer $MXM_TOKEN" \
  https://manager.example.com/api/domains/example.com/dmarc-policy

curl -sS -X PATCH -H "Authorization: Bearer $MXM_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"dmarc_record":"v=DMARC1; p=reject; sp=reject; aspf=r;"}' \
  https://manager.example.com/api/domains/example.com/dmarc-policy

Pass "dmarc_record": null to clear a custom policy and fall back to DMARC_RECORD from .env. Details: DNS health checks.

What tokens cannot do

• Open HTML pages as a substitute for logging in (use the API paths under /api/…).
• Manage other API tokens (create/revoke/list tokens requires an admin browser session).
• Register or delete domains on MXroute unless the token is admin-scoped (same as delegated users).

Security notes

• Treat mxm_ tokens like passwords. Revoke compromised tokens immediately under Access Control.
• Prefer narrow scopes: a DNS repair bot only needs dns on the domains it touches.
• Use HTTPS in production (FORCE_HTTPS=true). Tokens sent over plain HTTP can be intercepted.
• Audit events (mailbox.create, dns.health_alert, etc.) still log actions performed via tokens. See Audit Logs and Notifications.

Environment tweak

PUBLIC_URL_SCHEME (default https) controls the scheme used when the app builds public webmail URLs in mail-client settings. Rarely needed unless you run a non-TLS lab environment.

Related guides

Guide	Topic
Example scripts	PowerShell and Bash starters
Access control	Delegations, API tokens, permission matrix
Configuration	Env vars, production TLS
Notifications	DNS health alerts via Apprise
Adding a domain	Wizard and DNS fix behaviour
DNS health checks	SPF, DMARC, checklist semantics
Testing	test_api_tokens.py and route tests
